Naviate Road

Have access to templates and setting files for local standards, as well as functions that together with Civil 3D create an efficient workflow.

Customised for engineers

With Naviate Road are included templates that are designed to conform the Scandinavian national standards. The library of premade assemblies cover the most common road types and are open for you to edit and customise as you need. Assemblies can then be shared in a project or with coworkers with easy to use functions. Templates and setting files are included with the program and can be adapted to the users needs. Naviate can be used in English, Swedish and Norwegian.

Efficient road design
National standards

Efficient road design

Naviate Road includes functions for creating objects such as widenings for bus stops, sub surfaces for quick volume calculations and slope pattern. Objects created with Naviate are native Civil 3D objects which can be shared with any other Civil 3D user. Objects created with Naviate are gathered in Object Explorer which assists with keeping track of Naviate objects and gives user an easy place to find Update-functionality.

Project management

For project managers Naviate Road contain multiple commands to assist in updating assemblies and corridors across multiple drawings. The Project command automatically sets the users project folder for all Naviate commands. With both update and check tools for values in subassemblies, the project manager can easily check multiple assemblies and corridors in the project. Export functionality both to 3D objects and to excel for calculation purposes are available.

Learn more about Naviate Road

Import Assembly

You can create a library of your own Assemblies, on a local or network drive, to allow yourself or your colleagues to import into any other design.

Verify and Update Assembly

As the Naviate Import/Export Assembly tool handles versions, you can easily publish a new version and notify the consumers to automatically update the imported assembly.

Import Corridor Settings

You can import Corridor Settings from any Source Corridor, e.g. Frequency Settings, Surface Settings and Slope Patterns. Command is scriptable for batch update.

Export Corridor Solids to CSV

Solids can be divided into intervals along the alignment and Property Data are added accordingly. The command is also scriptable.

Find and Replace Subassembly Values

Performs Find and Replace on values (text, integer, or real) in selected subassemblies.

Export corridor feature lines

Exports selected feature lines/subassembly codes in a corridor to a coordinate-file or to feature lines, including the ability to use a translation file ro rename codes and layers.

Trusted by professionals

Tyrens Group Magnus Svensson
“The Naviate Road tools allow us to create a workflow to distribute and update our Assemblies and Corridor settings in our large projects. The tools allow us to make sure that everyone uses the correct versions and settings. The scripting abilities make it easy to update the full project after any changes to our Assemblies or Corridor settings and Symetri has been very helpful in adding new features to improve our workflows”
Magnus Svensson
BIM & Application Strategist
Tyréns Group

Trusted by professionals

Kier Professional Services Trevor Norman
Naviate is an extensive package that adds workflows and specific tool for our daily design process. The “ADMM Property Sets” creation tool saves us thousands of hours and eliminates human errors. Also the Corridor Setup and Export tools including the ability to use the translation command on sub-assemblies plus all the Property Set Management tools are saving us hundreds of hours, The Naviate team has also been very agile in adding new features that we have requested.
Trevor Norman
Principal CAD Technician
Kier Professional Services

Trusted by professionals

Daniel Alderholm Square
Naviate for Civil 3D is an excellent companion to Civil 3D. It is user-friendly and gives the user a lot of options to work with. Without Naviate, it would be hard to produce the models I require.
Daniel Alderholm
Construction Engineer
Loxia Group
