Naviate Traffic

Naviate Traffic works together with Autodesk Civil 3D surfaces to create a traffic model in both plan and 3D. Naviate Traffic includes libraries of signs and markings for Sweden, Norway, Finland, and the USA, and can be updated with user-created signs as well.

Customized for Traffic Planning

With Naviate Traffic, you can insert signs and sign holders from a predefined library straight into a Civil 3D environment. Road markings can be created around AutoCAD or Civil 3D objects. And, if you update the original objects, the Naviate signs and markings can be updated along with them.

Sign library
Sign creation

Creation of 3D Signs

Naviate Traffic can automatically create 3D objects of signs, sign holders, and markings. All traffic objects can have property sets applied to them which can be included in export to other software.

Learn more about Naviate Traffic

Add/Edit traffic sign

Editing an existing sign or add a sign to an existing sign / post. To add a sign, click "+" and select a new sign. To place it on the other side of the post, click "Inv". Repeat for other signs. The pole is changed automatically.

Insert traffic sign

Inserts a traffic sign in the drawing. Point out the location of the pole and then place the sign. Then point out a rotation for the post and sign or press Enter to not rotate. To change post press, enter before selecting location for the post.

Draw 3D Signs and Markings

Creates 3D traffic sign from existing 2D traffic signs. 3D traffic signs can be lifted to a an existing surface. Also creates 3D markings from existing 2D cross markings, longitudinal markings, other road markings and ghost islands.

Draw longitudinal markings

Creates longitudinal line marking on alignments, polylines or Feature Lines.

Draw cross markings

Draw cross markings eg Stop Line, Give Way line, Bicycle Overpass, Crosswalk.

Guidance Sign

Create Guidance Sign.
